Version 6.0 11 March 2010
Installation Manual 2. Installing the Device
Table 2-2: Rear Panel Component Descriptions
Item # Label Component Description
1
- RTM locking screws (or RTM latches).
2 ETH
Two 10/100Base-TX, RJ-45 shielded ports. This dual Ethernet
interface provides an Ethernet redundancy scheme (active /
standby), offering protection against Ethernet failure.
3
TRUNKS (16 spans)
-or-
PSTN (1, 2, 4, or 8
spans)
The connector depends on the number of required spans:
16 Spans: Two 50-pin female Telco connector (DDK 57AE-
40500-21D) for E1/T1 trunks 1 to 8, and 9 to 16 respectively.
1, 2, 4, or 8 Spans: Up to eight RJ-48c ports, each
supporting an E1/T1 trunk.
4
Protective earthing screw.
5 100-240~1.5A
or 48V 4A max
One of the following power interfaces (depending on customer
requirements):
Dual AC power sockets
2-Pin DC connector
