Version 6.0 23 March 2010
Installation Manual 3. Configuring the Device
3 Configuring the Device
This section describes initial, basic setup configuration for the device, using the device's
embedded Web server (Web interface).
Note: The device is supplied with application software (cmp file) already residing on
its flash memory. This software is set to factory defaults.
3.1 Assigning an IP Address
This section describes how to change the device's default IP address so that it corresponds
with your network environment. The table below lists the device's default IP address.
Table 3-1: Default IP Addresses
Parameter Default Value
IP Address
Device with a single module (trunks 1-8): 10.1.10.10
Device's second module (trunks 9-16): 10.1.10.11
Subnet Mask
255.255.0.0
Default Gateway IP Address
0.0.0.0
Note: The device can include one or two identical modules. These modules are fully
independent, each possessing its own MAC and IP address. If the device
includes two modules, the IP addresses assigned to these modules must be
in the same subnet.
To assign an IP address to the device, use one of the following methods:
Device's HTTP-based embedded Web server `accessed using a Web browser (refer to
'Assigning an IP Address using HTTP' on page 23).
BootP (refer to 'Assigning an IP Address using BootP' on page 25).
Embedd
ed Command Line Interface (CLI), accessed using RS-232 (if supported) or
Telnet (refer to 'Assigning an IP Address using the CLI' on page 26).
Dynamic Host Control Protocol (DHCP) - refer to the User's Manual.
Tip: If at a later stage after re-defining the IP address, your IP address is unknown
(e.g., forgotten), use the BootP/TFTP utility to access the device (refer to the
Product Reference Manual).
