Installation Manual 34 Document #: LTRT-70113
Mediant 2000
3.5 Backing Up and Restoring Configuration
You can save a copy/backup of the device's current configuration settings as an ini file to a
folder on your PC, using the 'Configuration File' page. The saved ini file includes only
parameters that were modified and parameters with other than default values. The
'Configuration File' page also allows you to load an ini file to the device. If the device has
"lost" its configuration, you can restore the device's configuration by loading the previously
saved ini file or by simply loading a newly created ini file.
Note:
When loading an ini file using this Web page, parameters not included in the
ini file are reset to default settings.
¾ To save and restore the ini file:
1. Open the 'Configuration File' page (Management tab > Software Update menu >
Configuration File).
2. To save the ini file to a folder on your PC, perform the following:
a. Click the Save INI File button; the 'File Download' dialog box appears.
b. Click the Save button, navigate to the folder in which you want to save the ini file
on your PC, and then click Save; the device copies the ini file to the selected
folder.
3. To load the ini file to the device, perform the following:
a. Click the Browse button, navigate to the folder in which the ini file is located,
select the file, and then click Open; the name and path of the file appear in the
field beside the Browse button.
b. Click the Load INI File button, and then at the prompt, click OK; the device
uploads the ini file and then resets (from the cmp version stored on the flash
memory). Once complete, the 'Enter Network Password' dialog box appears,
requesting you to enter your user name and password.
