Hardware Installation Manual 3. Physical Description
3.3.3 Ethernet LEDs Description
The blade provides LEDs for indicating Ethernet status, as described in the table below:
Table 3-5: Ethernet LEDs Description
Label Color Status Description
LINK
Green On Link all OK.
ACT
Yellow On Transmit / receive activity.
3.3.4 Blade Power LED Description
The blade provides a LED for indicating power status, as described in the table below:
Table 3-6: Blade Power LED Description
Label Color Status Description
PWR
Green On Power is supplied to the blade.
- Off No power is received by blade.
3.3.5 Blade Slot Installation LED Description
The blade provides a LED for indicating slot installation status, as described in the table
below:
Table 3-7: Blade Slot Installation LED Description
Label Color Status Description
SWAP READY
Blue On
The blade can be removed.
The blade is installed successfully.
