AudioCodes Mediant 3000 Hardware Installation Manual

Version 7.0 17 Mediant 3000
Hardware Installation Manual 3. Physical Description
3.2.2.1 Chassis with TP-6310 Blades
The slot assignment for blades and RTMs in the chassis for TP-6310 is described in the
table below.
Table 3-4: Slot Assignment for Mediant 3000 with TP-6310
Chassis
Panel
Slot # Simplex Mode HA Mode
Front
1 TP-6310 blade Active TP-6310 blade
2 Alarm, Status and
Synchronization (SA/M3K) blade
Active SA/M3K blade
Note: This blade operates with the
TP-6310 blade in Slot #1.
3 Slot covered by a blank panel Standby (redundant) TP-6310
blade.
4 Slot covered by a blank panel Standby SA/M3K blade
Note: This blade operates with the
TP-6310 blade in Slot #3.
Rear
1 Slot covered by a blank panel Slot covered by a blank panel
2 RTM-
6310 providing the following
interfaces:
 GbE
 1+1 STM-1/OC-3
or up to 3 x T3 interfaces
RTM-6310 providing the following
interfaces:
 GbE
 1+1 STM-1/OC-3
or up to 3 x T3 interfaces
3 Slot covered by a blank panel RTM-6310 Redundancy
4 Slot covered by a blank panel Slot covered by a blank panel
