AudioCodes Mediant 3000 Hardware Installation Manual

Hardware Installation Manual 42 Document #: LTRT-94720
Mediant 3000
Function Specification
Safety Standards
EN 60950-1, UL 6050-1
AC Input
PEM/AC
Power Entry Module for AC
Input
100 to 240 V AC 50/60 Hz, 8A Max
The Power Supply module provides LEDs on its front panel, as described in the table
below.
Table 3-19: AC Power Supply (PS/AC/3K) Module LEDs Description
LED Color Status Description
FAULT Yellow
On Power supply failure.
--
Off Normal operation.
POWER Green
On Power is supplied to the blade.
--
Off No power is supplied to the blade.
3.8.2 DC Power System
The DC power system is powered by two DC redundant feeds (providing 1+1 power
redundancy) and consists of the following hardware components:

Power Entry Module (PEM/DC/3K) – see Section 3.8.2.1 on page 43

Power Supply Module (PS/DC/3K) – see Section 3.8.2.2 on page 44
Warnings:
• Use two separate DC power sources for power redundancy to avoid total power
failure in case one of the DC power sources fails.
• When using DC power as the primary input, ensure that the output is SELV, as
defined by the safety standard requirements CAN/CSA-C22.2 No. 60950-1UL 60950-
1, and EN 60950-1.
The table below lists the device's DC power specifications.
Table 3-20: DC Power Supply Specifications
Parameter Value
Power Requirements
-40.5 to -60 VDC
Power Consumption
 Mediant 3000 with TP-6310:

OC-3/STM-1 Simplex: 4.5A @ 48 VDC, 216W

OC-3/STM-1 HA: 7.1A @ 48 VDC, 343W
 Mediant 3000 with TP-8410:

16E1/21T1 Simplex: 3.1A @ 48 VDC, 150W

16E1/21T1 HA: 4.4A @ 48 VDC, 211W

63E1/84T1 Simplex: 4.4A @ 48 VDC, 211W
 63E1/84T1 HA: 7A @ 48 VDC, 336W
Connection Provisions
PEMs with input block terminals
