6.2 Replacing Blades and RTMs
This section describes how to replace the blades and RTMs in the chassis. The blades and
RTMs provide ejector / injector latches on either side (see the figure below) to secure them
to the chassis cage slots.
Figure 6-1: Ejector/Injector Latches on Blade/RTM
Note: It is imperative to cover unoccupied slots with blank panels (see the figure below)
in the chassis' front and rear slot cages to maintain internal airflow pressure.
Figure 6-2: Blank Panel for Unoccupied Slots
