Gateway & E-SBC 53 Mediant 800
Hardware Installation Manual 6. Maintenance – Replacing the Power Fuse
6 Maintenance – Replacing the Power Fuse
The device contains a fuse that protects the device from excessive AC current. The fuse is
located on the rear panel, below the power socket. To replace the fuse, use only one of the
following fuses described in the table below:
Table 6-1: Allowed Fuses for the Device
Manufacturer Manufacturer Part Number
LITTEFUSE 215 06.3 (6.3A/250V)
Caution
For continuous protection, replace only with the same fuse type and rating fuse.
Notes: The power fuse is applicable only to AC power.
To replace the fuse:
1. Unplug the power cord from the electrical outlet.
2. Using a small flathead screwdriver, gently pries open the fuse cavity as illustrated in the
figure below:
Figure 6-1: Opening the Fuse Cavity
