AudioCodes MediaPack 124 User Manual

MediaPack Analog Gateways 9 MP-124
Hardware Installation Manual 1. Introduction
1 Introduction
This document provides a hardware description of the MediaPack MP-124 product
(hereafter, referred to as device) and step-by-step procedures for cabling the device.
The MP-124 series includes the following models:
Table 1-1: MP-124 Models and Support
Model FXS Ethernet Serial Power
MP-124 Rev. D
24 1 DB-9 AC or DC
MP-124 Rev. E
(MP124E/FXS/AC)
24
1
RJ-45 AC Only
Note:
• MP-124 Rev. E is supported only from SIP Software Version 6.60A.301.
• Although the supported software functionality and configuration of MP-124 Rev. D
and MP-124 Rev. E are identical, they use different software firmware files (.cmp):
√ MP-124 Rev. E: MP124E_SIP_<version>.cmp
√ MP-124 Rev. D: MP124_SIP_<version>.cmp

AudioCodes MediaPack 124 Specifications

General

Brand	AudioCodes
Model	MediaPack 124
Category	Gateway
Language	English
