CHAPTER3 Physical Description
Mediant 1000 Gateway & E-SBC | Hardware Installation Manual
Color Description
cannot be identified.
Contact support@audiocodes.com if you purchased the device / MPM from
AudioCodes or if you're subscribed to AudioCodes Customer Technical Support
(ACTS).
CRMX Module
The CRMX module provides LAN Ethernet interfaces, dry-contact alarm interfaces, and other
system functionality.
Ports Description
The port interfaces provided by the CRMX module are shown in the following figure and
described in the subsequent table.
■ CRMX Module without Dry-Contact Relays:
● New Hardware Revision:
- 10 -
