CHAPTER3 Physical Description
Mediant 1000 Gateway & E-SBC | Hardware Installation Manual
Item # Label Description
5 HDMX HDMX module for hard drive storage (HDD or SSD) on OSN server
platform.
Note: The AMC chassis slots must only be installed with AMC
modules that have been approved and homologated by
AudioCodes.
6 HDMX Slot for second, optional HDMX module for hard drive storage
(HDD or SSD) on OSN server platform.
7 - Unused and covered AMC module slots.
Note: The AMC chassis slots must only be installed with AMC
modules that have been approved and homologated by
AudioCodes.
OSN Server Modules
The optional OSN platform consists of the following two modules, which are installed on the
rear panel:
■ OSN module (OSN4B) - see OSN4B Module
■ HDMX module – see HDMX Module
OSN4B Module
The OSN4B module provides the port connector interfaces and is housed in Slot #2 on the rear
panel.
Specification
Table 3-13: OSN Server Specification
OSN
Platform
CPU Memory Storage Interfaces
OSN4B Intel®
Xeon®
D1527
16 GB DDR4
with ECC
Up to 2 hard drives:
HDD or SSD
■ Two external
Gigabit
Ethernet
■ Internal Gigabit
Ethernet
■ USB 2.0
■ RS-232 COM
■ HDMI Graphic
- 18 -
