Port Description
The OSN module is shown below and described in the subsequent table.
Figure 3-12: OSN4B Module Port
Table 3-14: OSN4B Module Port Description
Item # Label Description
1 USB 2.0 port.
2 RJ-45 port for Gigabit Ethernet. The interface provides automatic
detection and switching between 10Base-T, 100Base-TX and
1000Base-T data transmission (Auto-Negotiation). Auto-wire
switching for crossed cables is also supported (Auto-MDI/X).
3 Console (serial) port (micro-USB) for serial interface (COM1).
4 HDMI Micro-HDMI port (19-pin Type D) for connecting to a graphic display
monitor.
5 Reset pinhole button.
■ To warm reset the operating system of the OSN server (i.e., power
remains on): Press and then immediately release the button (less
than five seconds). The LED indications are as follows (see LED
Description for LED locations):
✔ Upon reset:
● LED #1: On (solid green)
- 19 -
