CHAPTER4 Mounting the Device
Mediant 1000 Gateway & E-SBC | Hardware Installation Manual
8. Hold the chassis in position while the second person secures the two front-mounting
brackets to the front posts, by finger-tightening 19-inch rack bolts (not supplied) to the rack
posts.
9. Tighten the bolts on the front-mounting brackets.
10. With a Philips screwdriver, tighten the screws securing the rear-mounting flanges to the
rear-mounting brackets.
● Make sure that all the mounting brackets are attached at the same level to the
mounting posts so that the chassis is supported in a horizontal position.
● If the depth of the rack exceeds the maximum length of the adjustable rear-
mounting brackets, install an additional side rack post to accommodate the
length of the Rear-Mounting Bracket.
- 32 -
