10. TECHNICAL SPECIFICATIONS
POWER SUPPLY
Power supply voltage / fuse: 11 ÷ 15 VDC / 2 x 30A
Operating power supply voltage: 6.5V ÷17V
Idling current: 1.6 A
Switched off without DRC: 1.7 mA
Switched off with DRC: 5 mA
Consumption @ 14.4 VDC, 2Ω, Max Musical Power: 55 A
Remote IN: 6 ÷15 VDC (1 mA)
Remote OUT: 4 ÷15 VDC (150 mA)
ART - Automatic Remote Turn on/off from OUTPUT BTL
speakers (Selectable):
2 ÷7 VDC
AST - Automatic Signal Turn on/off (Selectable): Speaker-In
AMPLIFIER STAGE
Distortion - THD @ 1 kHz, 4Ω, 70% Rated Power: 0.06 %
Damping factor @ 1 kHz, 4Ω, 2 VRMS: > 110
Bandwidth @ -1.5 dB: 10Hz ÷ 22 kHz
S/N ratio (A weighted @ 1 V Input) Master Input: 100 dBA
S/N ratio (A weighted @ 1 V Input) Optical Input: 105 dBA
Input sensitivity Pre-In: 0.6 ÷ 6 VRMS
Input sensitivity Speaker-In: 2.2 ÷ 22 VRMS
Minimum load impedance: 8Ch: 2Ω
4Ch - (Bridge 1/2; 3/4; 5/6; 7/8): 4Ω
Output power (RMS) @14.4 VDC, 1% THD:
• 8 Ch @ 4Ω: 85 W x 8
• 8 Ch @ 2Ω: 130 W x 8
• 4Ch (Bridge 1/2; 3/4; 5/6; 7/8) @ 4Ω:
260 W x 4
INPUTS / OUTPUTS
Pre-In Inputs: Ch1 ÷ Ch6 customizable
Speaker-In Inputs: Ch1 ÷ Ch6 customizable
Digital IN: 1 x Optical S/PDIF; Max 192 kHz / 24 bit
Sub Out (RCA Pre Out): 4 VRMS
DIGITAL SIGNAL PROCESSOR
Filter type: Full / Hi pass / Low Pass / Band Pass
Filter mode and slope: Linkwitz @ 12/24 dB
Butterworth @ 6/12/18/24 dB
Crossover frequency: 68 steps @ 20 ÷ 20k Hz
Phase control: 0° / 180°
Bass Boost N.1 Adjustable Parametric Pole
Analog Input Equalizer (20 ÷ 20k Hz): Automatic De-Equalization
Output Equalizer: N.9 Parametrics Equalizers: ±12 dB;10 pole; 20 ÷ 20k Hz
Time Alignment Distance: 0 ÷ 510 cm / 0 ÷ 200.8 inches
Time Alignment Delay: 0 ÷ 15 ms
Time Alignment Step: 0.08 ms; 2.8 cm / 1.1 inch
Time Alignment Fine SET: 0.02 ms; 0.7 cm / 0.27 inch
Preset (Drive Preset): Rotary switch for 7 installation Presets
Acoustic Preset: N.2 DSP Memory, DRC selectable
CONTROL CONNECTIONS
From / to personal computer: 1 x micro USB-B
To Audison DRC AB / MP: 1 x AC Link
Optical select: Optical select wire control +12 V enable
Master enable: Master enable wire control +12 V enable
GENERAL REQUIREMENTS
PC connections: Micro USB 1.1 / 2.0 / 3.0 Compatible
Software/ PC requirements: Microsoft Windows (32/64 bit): Vista,Win 7, Win 8, Win 10
Video resolution with screen resize: min. 1024 x 600
Ambient operating temperature range: 0 °C to 55 °C (32 °F to 131 °F)
SIZE / WEIGHT
Max size W x H x D (mm/inch): 238 x 49,5 x 155 / 9.37 x 1.95 x 6.1
Weight (kg/lb): 1,98 / 4.36
