26
Digital domainClassic domain
OWNER’S MANUAL / TH quattro
24 dB
180 Hz
24 dB 12 dB
180 Hz
180 1.8k Hz
Hi-pass Lo-pass
24 dB 24 dB 12 dB
Electronic Crossover
Setup Lo-pass Xover Slope 24 dB
When the amplifier is set up in a mono configuration, and ASC is set
at 24 dB Oct., it is anyway possible to set the crossover Low-pass at
12 or 24 dB Oct.
- The TH-MXR.1 board must be inserted;
- You need to operate on the TH-MXR.1 switch. Through the Status
Monitor it is possible to check anytime the presence of the filter as
well as the set slope.
TH in 3 Ch Mode
Filtering B channels
