Audison Thesis TH quattro - System Integration & Software; ACNet Control Network

59
OWNER’S MANUAL / TH quattro
Digital domain
0
5
8
7
64
3
2
19
IN A
OUT A
IN A
IN B
IN B
OUT A
DIGITAL AUDIODC OUT CONTROL BUS
REM
OUTINADRS
IN
OPTICAL
GND
+15
-15
OUT - AD Link - IN
LR LR
LR
LR
LRLR
1 - AC Link - 2
RJ12 (Provided)
USB (Provided)
USB/AC Link
(Provided)
Rear Panel
Front Panel
Software to control Audison amplifier
1 - Switch on the PC
2 - Switch on the amplifier
3 - Connect the AC Link to the RJ-12 cable from
the TH to the USB/AC Link converter
4 - Connect the USB cable from USB/AC
Link converter to PC
5 - Wait 5/10 secs until the PC recognizes
the USB connection
6 - Launch the ACNet software
7 - If everything is OK the PC monitor
displays the software main page.
Hardware Requirements:
1024x768 Display Optimized - 96 dpi Font size - 1 x USB port (1.1 compliant)
ACNet - Audison Control Network
