46
OWNER’S MANUAL / TH quattro
Digital domain
UP
DOWN
UP
DOWN
DOWN
UP
UP
DOWN
MENU
ENTER ENTER
OWN
OWN
OWN
ASC - Amplifier Status Controller
When the amplifier is set in 3 Ch Mode, you can choose the crossover filter slope of the B (bridged)
channels.
Select 1- 12 dB/oct: in this case, the Low-pass slope switch on the TH-MXR module will not be active.
Select 2- 24 dB/oct: when this option is selected, the Low-pass slope switch on the TH-MXR module will
anyway be active, thus providing the ability to mechanically choosing between 12 and 24 dB/oct.
For further information see page 23 ÷ 27
Setup Amplifier : X-Over Slope of bridged channels (B)
with TH quattro in 3 Ch mode
TH quattro in 2 Ch mode
PRESS ENTER TO CONFIRM YOUR
SELECTION AND MOVE TO THE
NEXT SETUP
PRESS
ENTER TO
REACH
Default Value
When the amplifier is set in 2 Ch Mode, crossover filter slope is always 12 dB/oct.
