Table 6:
Dimensions Part-turn actuators SQ 05.2 – SQ 14.2 / SQR 05.2 – SQR 14.2
with 3-phase AC motors
Weight with base and lever
2)
Weight
1)
Type designation
Actuator
approx. [kg]approx. [kg]
2721SQ 05.2/
SQR 05.2
2721SQ 07.2/
SQR 07.2
3126SQ 10.2/
SQR 10.2
4335SQ 12.2/
SQR 12.2
5544SQ 14.2/
SQR 14.2
Indicated weight includes AUMA NORM part-turn actuator with 3-phase AC motor, electrical con-
nection in standard version, unbored coupling and handwheel. For other output drive types, consider
additional weights.
1)
lndicated weight includes AUMA NORM part-turn actuator with 3-phase AC motor, electrical connec-
tion in standard version, and handwheel, including base and lever. For other output drive types,
consider additional weights.
2)
Table 7:
Dimensions Part-turn actuators SQ 05.2 – SQ 14.2 / SQR 05.2 – SQR 14.2
with 1-phase AC motors
Weight with base and lever
2)
Weight
1)
Type designation
Actuator
approx. [kg]approx. [kg]
2923SQ 05.2/
SQR 05.2
2923SQ 07.2/
SQR 07.2
3228SQ 10.2/
SQR 10.2
4537SQ 12.2/
SQR 12.2
5746SQ 14.2/
SQR 14.2
Indicated weight includes AUMA NORM part-turn actuator with 1-phase AC motor, electrical con-
nection in standard version, unbored coupling and handwheel. For other output drive types, consider
additional weights.
1)
Indicated weight includes AUMA NORM part-turn actuator with 1-phase AC motor, electrical con-
nection in standard version, and handwheel, including base and lever. For other output drive types,
consider additional weights.
2)
4.2. Storage
Risk of corrosion due to inappropriate storage!
→
Store in a well-ventilated, dry room.
→
Protect against floor dampness by storage on a shelf or on a wooden pallet.
→
Cover to protect against dust and dirt.
→
Apply suitable corrosion protection agent to uncoated surfaces.
14
SQ 05.2 – SQ 14.2/SQR 05.2 – SQR 14.2 Control unit: electronic (MWG)
Transport and storage AC 01.2 Non-Intrusive
