With base and lever (option)
Made of spheroidal cast iron with two or three bores for fixing a lever arrangement. Considering the in-
stallation conditions, the lever may be mounted to the output shaft in any desired position.
Swing lever
Two ball joints matching the lever, including lock nuts and two welding nuts, suitable for pipe according
to dimension sheet
Ball joints (option)
Base with four holes for fastening screwsFixing
Electronic control unit
Magnetic limit and torque transmitter (MWG)Non-Intrusive setting
Via actuator controlsPosition feedback signal
Via actuator controlsTorque feedback signal
Continuous self-adjusting indication with symbols OPEN and CLOSEDMechanical position indicator
Blinking signal via actuator controlsRunning indication
Resistance type heater with 5 W, 24 V ACHeater in switch compartment
Service conditions
Indoor and outdoor use permissibleUse
Any positionMounting position
≤ 2,000 m above sea level
> 2,000 m above sea level on request
Installation altitude
Refer to actuator name plateAmbient temperature
Up to 100 % relative humidity across the entire permissible temperature rangeHumidity
IP68 with AUMA 3-phase AC motor/1-phase AC motor
For special motors differing enclosure protection available (refer to motor name plate)
Standard:Enclosure protection according to
EN 60529
Terminal compartment additionally sealed against interior of actuator (double sealed)Option:
According to AUMA definition, enclosure protection IP68 meets the following requirements:
●
Depth of water: maximum 8 m head of water
●
Duration of continuous immersion in water: Max. 96 hours
●
Up to 10 operations during immersion
●
Modulating duty is not possible during immersion
For exact version, refer to actuator controls name plate.
Pollution degree 4 (when closed), pollution degree 2 (internal)Pollution degree according to IEC
60664-1
2 g, 10 to 200 Hz (AUMA NORM), 1 g, 10 to 200 Hz (for actuators with AM or AC integral controls)
Resistant to vibration during start-up or for failures of the plant. However, a fatigue strength may not be
derived from this.Valid for part-turn actuators in version AUMA NORM and in version with integral actu-
ator controls, each with AUMA plug/socket connector. Not valid in combination with gearboxes.
Vibration resistance according to
IEC 60068-2-6
KS: Suitable for use in areas with high salinity, almost permanent condensation, and high
pollution.
Standard:Corrosion protection
KX: Suitable for use in areas with extremely high salinity, permanent condensation, and
high pollution.
Option:
KX-G: Same as KX, however aluminium-free version (outer parts)
Double layer powder coating
Two-component iron-mica combination
Coating
AUMA silver-grey (similar to RAL 7037)Standard:Colour
Available colours on requestOption:
AUMA part-turn actuators meet or even exceed the lifetime requirements of EN 15714-2. Detailed in-
formation can be provided on request.
Lifetime
Further information
Machinery Directive 2006/42/EC
Low Voltage Directive 2014/35/EU
EMC Directive 2014/30/EU
RoHS Directive 2011/65/EU
RED Directive 2014/53/EU
EU Directives
71
SQ 05.2 – SQ 14.2/SQR 05.2 – SQR 14.2 Control unit: electronic (MWG)
AC 01.2 Non-Intrusive Technical data
