Features and functions
6 programmable output contacts:
-
5 potential-free NO contacts with one common, max. 250 V AC, 1 A (resistive
load)
Default configuration: End position CLOSED, end position OPEN, selector switch
REMOTE, fault CLOSE, torque fault OPEN
-
1 potential-free change-over contact, max. 250 V AC, 5 A (resistive load)
Default configuration: Collective fault signal (torque fault, phase failure, motor
protection tripped)
Analogue output signal for position feedback
-
Galvanically isolated position feedback 0/4 20 mA (load max. 500 Ω)
Standard:Status signals
(output signals)
6 programmable output contacts:
-
5 change-over contacts with one common, max. 250 V AC, 1 A (resistive load),
1 potential-free change-over contact, max. 250 V AC, 5 A (resistive load)
12 programmable output contacts:
-
10 potential-free NO contacts, 5 with one common each, max. 250 V AC, 1 A
(resistive load), 2 potential-free change-over contacts, max. 250 V AC, 5 A (resistive
load)
6 programmable output contacts:
-
6 potential-free change-over contacts without one common, per contact max.
250 V AC, 5 A (resistive load)
10 programmable output contacts:
-
10 potential-free change-over contacts without one common, per contact max.
250 V AC, 5 A (resistive load)
6 programmable output contacts:
-
4 mains failure proof potential-free NO contacts with one common, max. 250 V
AC, 1 A (resistive load), 1 potential-free NO contact, max. 250 V AC, 1 A (resistive
load), 1 potential-free change-over contact, max. 250 V AC, 5 A (resistive load)
6 programmable output contacts:
-
4 mains failure proof potential-free NO contacts, max. 250 V AC, 5 A (resistive
load), 2 potential-free change-over contacts, max. 250 V AC, 5 A (resistive load),
12 programmable output contacts:
-
8 mains failure proof potential-free NO contacts, max. 250 V AC, 1 A (resistive
load), 2 potential-free NO contacts, max. 250 V AC, 1 A (resistive load), 2 potential-
free change-over contacts, max. 250 V AC, 5 A (resistive load)
12 programmable output contacts:
-
8 mains failure proof potential-free NO contacts, max. 250 V AC, 5 A (resistive
load), 4 potential-free change-over contacts, max. 250 V AC, 5 A (resistive load),
All output signals must be supplied with the same potential.
Options:
Additional, binary output signals (only available in combination with additional input signals (option))
These output signals are not available via DeviceNet interface.
6 programmable output contacts:
-
5 potential-free NO contacts with one common, max. 250 V AC, 1 A (resistive load)
Default configuration: End position CLOSED, end position OPEN, selector switch REMOTE,
torque fault CLOSE, torque fault OPEN
-
1 potential-free change-over contact, max. 250 V AC, 5 A (resistive load)
Default configuration: Collective fault signal (torque fault, phase failure, motor protection tripped)
6 programmable output contacts:
-
5 potential-free change-over contacts with one common, max. 250 V AC, 1 A (resistive load)
-
1 potential-free change-over contact, max. 250 V AC, 5 A (resistive load)
6 programmable output contacts:
-
6 potential-free change-over contacts without one common, max. 250 V AC, 5 A (resistive load)
6 programmable output contacts:
-
4 mains failure proof potential-free NO contacts with one common, max. 250 V AC, 1 A (resistive
load), 1 potential-free NO contact, max. 250 V AC, 1 A (resistive load), 1 potential-free change-
over contact, max. 250 V AC, 5 A (resistive load)
6 programmable output contacts:
-
4 mains failure proof potential-free NO contacts, max. 250 V AC, 5 A (resistive load), 2 potential-
free change-over contacts, max. 250 V AC, 5 A (resistive load),
All binary output signals must be supplied with the same potential.
Analogue output signal for position feedback
-
Galvanically isolated position feedback 0/4 20 mA (load max. 500 Ω)
with additional output signals (op-
tion)
73
SQ 05.2 SQ 14.2/SQR 05.2 SQR 14.2 Control unit: electronic (MWG)
AC 01.2 Non-Intrusive Technical data
