Features and functions
●
EMERGENCY operation (programmable behaviour)
-
Digital input: Low active
-
Reaction can be selected: Stop, run to end position CLOSED, run to end position
OPEN, run to intermediate position
-
Torque monitoring can be by-passed during EMERGENCY operation
-
Thermal protection can be by-passed during EMERGENCY operation (only in
combination with thermoswitch within actuator, not with PTC thermistor).
Standard:Safety functions
●
Enabling local controls via digital input Enable LOCAL. Thus, actuator operation can
be enabled or disabled via push buttons on local controls.
●
Interlock for main/by-pass valve: Enabling the operation commands OPEN or CLOSE
via two digital inputs
●
EMERGENCY Stop push button (latching): Interrupts electrical operation, irrespective
of the selector switch position
●
PVST (Partial Valve Stroke Test): programmable to check the function of both actuator
and actuator controls: Direction, stroke, operation time, reversing time
Options:
●
Valve overload protection: Adjustable, results in switching off and generates fault signal
●
Motor temperature monitoring (thermal monitoring): Results in switching off and generates fault
signal
●
Monitoring the heater within actuator: Generates warning signal
●
Monitoring of permissible on-time and number of starts: Adjustable, generates warning signal
●
Operating time monitoring: Adjustable, generates warning signal
●
Phase failure monitoring: Results in switching off and generates fault signal
●
Automatic correction of rotation direction upon wrong phase sequence (3-ph AC current)
Monitoring functions
●
Electronic device ID with order and product data
●
Operating data logging: A resettable counter and a lifetime counter each for:
-
Motor running time, number of starts, torque switch trippings in end position CLOSED, limit
switch trippings in end position CLOSED, torque switch trippings in end position OPEN, limit
switch trippings in end position OPEN, torque faults CLOSE, torque faults OPEN, motor protection
trippings
●
Time-stamped event report with history for setting, operation and faults
●
Status signals according to NAMUR recommendation NE 107: "Failure", "Function check", "Out of
specification", "Maintenance required"
●
Torque characteristics (for version with MWG in actuator):
-
3 torque characteristics (torque-travel characteristic) for opening and closing directions can be
saved separately.
-
Torque characteristics stored can be shown on the display.
Diagnostic functions
Monitoring the motor temperature in combination with thermoswitches within actuator
motor
Standard:Motor protection evaluation
●
Thermal overload relay in controls combined with thermoswitches within actuator
●
PTC tripping device in combination with PTC thermistors within actuator motor
Options:
AUMA plug/socket connector with screw-type connectionStandard:Electrical connection
Gold-plated control plug (sockets and plugs)Option:
Metric threadsStandard:Threads for cable entries
●
Pg-threads, NPT-threads, G-threads
●
Terminals or crimp-type connection
Options:
Refer to name plateWiring diagram
Further options for Non-intrusive version with MWG in the actuator
Setting of limit and torque switching via local controls
Galvanically isolated analogue output 0/4 – 20 mA (load max. 500 Ω).Torque feedback signal
75
SQ 05.2 – SQ 14.2/SQR 05.2 – SQR 14.2 Control unit: electronic (MWG)
AC 01.2 Non-Intrusive Technical data
