Read operation instructions first.
●
Observe safety instructions.
●
These operation instructions are part of the product.
●
Preserve operation instructions during product life.
●
Pass on instructions to any subsequent user or owner of the product.
Purpose of the document:
This document contains information for installation, commissioning, operation and maintenance staff. It is intended
to support device installation and commissioning.
Reference documents:
●
Manual (Operation and setting) AUMATIC AC 01.1/ACExC 01.1 Modbus
●
Manual (Device integration Fieldbus) AUMATIC AC 01.1/ACExC 01.1 Modbus
Reference documents can be downloaded from the Internet (www.auma.com) or ordered directly from AUMA
(refer to <Addresses>).
Table of contents Page
51. Safety instructions.................................................................................................................
51.1. Basic information on safety
51.2. Range of application
61.3. Applications in Ex zone 22 (option)
61.4. Warnings and notes
71.5. References and symbols
82. Identification...........................................................................................................................
82.1. Name plate
92.2. Short description
103. Transport, storage and packaging........................................................................................
103.1. Transport
103.2. Storage
103.3. Packaging
114. Assembly................................................................................................................................
114.1. Mounting position
114.2. Handwheel fitting
124.3. Multi-turn actuator: mount to valve/gearbox
124.3.1 Output drive types B, B1 – B4 and E
124.3.1.1 Multi-turn actuator (with output drive types B1 – B4 or E): mount to valve/gearbox
134.3.2 Output drive type A
134.3.2.1 Stem nut: finish machining
144.3.2.2 Multi-turn actuator (with output drive type A): mount to valve
154.4. Accessories for assembly
154.4.1 Stem protection tube for rising valve stem
154.5. Mounting positions of local controls
164.5.1 Mounting positions: modify
175. Electrical connection.............................................................................................................
175.1. Basic information
195.2. Connection with AUMA plug/socket connector
195.2.1 Terminal compartment: open
205.2.2 Cable connection
2
SA 07.1 – SA 16.1/SAR 07.1 – SAR 16.1 Control unit: electromechanic
Table of contents AC 01.1 Intrusive Modbus RTU
