10.2.1 Status indication S0 - faults and warnings
Line 4 of status indication S0 displays faults and warnings.
LOCAL MODE S0
OPEN
E2 100 %
FAULT IND.
Table 10: Description of the fault indications
RemedyDescriptionSignal
For further information, press and go to
status indication S1.
A fault has occurred.
FAULT IND.
For further information, press and go to
status indication S2.
A warning has occurred.
WARNING IND.
For further information, press and go to
status indication S1 (faults) or S2 (warnings).
Faults as well as warnings have occurred.
FAULT + WARNING
For further information, press and go to
status indication S3 (cause for fault indicati-
ons).
The actuator cannot be operated from REMO-
TE.The actuator can only be operated via
the local controls.
NOT READY IND.
For further information, press and go to
status indication S1 or S3.
Faults and the NOT READY IND. signal
have occurred.
FLT + NR
For further information, press and go to
status indication S2 or S3.
Warnings and the NOT READY IND. si-
gnal have occurred.
WRN + NR
For further information, press and go to
status indications S1 to S3.
Faults, warnings, and the NOT READY
IND. signal have occurred.
FLT + WRN + NR
10.2.2 Status indication S1 - faults
Faults are indicated within the status indication S1:
FAULT IND. S1
NO FAULT
Table 11: Description of the fault indications
RemedyDescriptionSignal
No fault has occurred.
NO FAULT
For further information:
1.
Go to group D0: Press C and hold it
down until diagnostic indication D0 is
displayed.
2.
Go to diagnostic indication D2: Press
twice.
Internal fault has occurred.
INTERNAL FAULT
Operation command in direction OPEN.Torque fault in direction CLOSE.
TORQUE FAULT (CLOSE)
Set selector switch to position Local control
(LOCAL) and reset fault indication via push
button Reset.
Or:
Perform reset command via fieldbus.
Operation command in direction CLOSE.Torque fault in direction OPEN.
TORQUE FAULT (OPEN)
Set selector switch to position Local control
(LOCAL) and reset fault indication via push
button Reset.
Or:
Perform reset command via fieldbus.
55
SA 07.1 – SA 16.1/SAR 07.1 – SAR 16.1 Control unit: electromechanic
AC 01.1 Intrusive Modbus RTU Corrective action
