Table 33:
Faults and warnings via status indications in the display
RemedyDescription/causeIndication on display
For a description of the status texts, refer to Manual
(Operation and setting).
Instead of the valve position, a status text is dis-
played.
S0001
For indicated value > 0: Press push button De-
tails.
For details, refer to <Warnings and Out of specific-
ation> table.
Collective signal 02:
Indicates the number of active warnings.
S0005
Warnings
For indicated value > 0: Press push button De-
tails.
For details, refer to <Not ready REMOTE and
Function check> table.
Collective signal 04:
Indicates the number of active signals.
S0006
Not ready REMOTE
For indicated value > 0: Press push button Details
to display a list of detailed indications.
For details, refer to <Faults and Failure> table.
Collective signal 03:
Indicates the number of active faults.
The actuator cannot be operated.
S0007
Fault
For indicated value > 0: Press push button De-
tails.
For details, refer to <Warnings and Out of specific-
ation> table.
Collective signal 07:
Indication according to NAMUR recommendation
NE 107
Actuator is operated outside the normal operation
conditions.
S0008
Out of specification
For indicated value > 0: Press push button De-
tails.
For details, refer to <Not ready REMOTE and
Function check> table.
Collective signal 08:
Indication according to NAMUR recommendation
NE 107
The actuator is being worked on; output signals are
temporarily invalid.
S0009
Function check
For indicated value > 0: Press push button Details
to display a list of detailed indications.
Collective signal 09:
Indication according to NAMUR recommendation
NE 107
Recommendation to perform maintenance.
S0010
Maintenance required
For indicated value > 0: Press push button Details
to display a list of detailed indications.
For details, refer to <Faults and Failure> table.
Collective signal 10:
Indication according to NAMUR recommendation
NE 107
Actuator function failure, output signals are invalid
S0011
Failure
Table 34:
Warnings and Out of specification
RemedyDescription/causeIndication on display
Press push button Details to display a list of indi-
vidual indications.
For a description of the individual signals, refer to
Manual (Operation and setting).
Collective signal 06:
Possible cause:
Configuration setting is incorrect.
The device can still be operated with restrictions.
Config. warning
Press push button Details to display a list of indi-
vidual indications.
For a description of the individual signals, refer to
Manual (Operation and setting).
Collective signal 15:
Device warnings
The device can still be operated with restrictions.
Internal warning
Check 24 V DC voltage supply.The external 24 V DC voltage supply of the controls
has exceeded the power supply limits.
24 V DC external
●
Check modulating behaviour of actuator.
●
Check parameter Perm. run time M0356, re-set
if required.
Warning on time max. running time/h exceeded
Wrn op.mode run time
●
Check modulating behaviour of actuator.
●
Check parameter Permissible starts M0357, re-
set if required.
Warning on time max. number of motor starts
(starts) exceeded
Wrn op.mode starts
Verify signals:
●
Setpoint E1
●
Actual value E2
●
Actual process value E4
●
Check connection to master.
●
Check (clear) status of master.
The failure behaviour is active since all required
setpoints and actual values are incorrect.
Failure behav. active
73
SAEx 07.2 – SAEx 16.2/SAREx 07.2 – SAREx 16.2 Control unit - electromechanical
ACExC 01.2 Intrusive Profinet Corrective action
