AUMA SAV 07.2 User Manual

Table 4:
Weights for multi-turn actuators SAV 07.2 – SAV 16.2 / SARV 07.2 – SARV 16.2
with 3-phase AC motors
approx. [kg]Motor type
1)
Type designation
Actuator
Weight
2)
20AD...SAV 07.2/
SARV 07.2
21AD...SAV 07.6/
SARV 07.6
25AD...SAV 10.2/
SARV 10.2
48AD...SAV 14.2/
SARV 14.2
53AD...SAV 14.6/
SARV 14.6
79AD...SAV 16.2/
SARV 16.2
Refer to motor name plate1)
Indicated weight includes AUMA NORM multi-turn actuator with 3-phase AC motor, electrical con-
nection in standard version, output drive type B1 and handwheel. For other output drive types, heed
additional weights.
2)
Table 5:
Weights for output drive type A 07.2 – A 16.2
[kg]Flange sizeType designation
1.1F07A 07.2
2.8F10A 10.2
6.8F14A 14.2
11.7F16A 16.2
Table 6:
Weights for output drive type AF 07.2 – AF 16.2
[kg]Flange sizeType designation
5.2F10AF 07.2
5.2F10AF 07.6
5.5F10AF 10.2
13.7F14AF 14.2
23F16AF 16.2
3.2. Storage
Danger of corrosion due to inappropriate storage!
→
Store in a well-ventilated, dry room.
→
Protect against floor dampness by storage on a shelf or on a wooden pallet.
→
Cover to protect against dust and dirt.
→
Apply suitable corrosion protection agent to uncoated surfaces.
Long-term storage
For long-term storage (more than 6 months), observe the following points:
1. Prior to storage:
Protect uncoated surfaces, in particular the output drive parts and mounting
surface, with long-term corrosion protection agent.
2. At an interval of approx. 6 months:
Check for corrosion. If first signs of corrosion show, apply new corrosion protec-
tion.
14
