AUMA SAV 07.2 - Default Chapter; Table of Contents

Read operation instructions first.
●
Observe safety instructions.
●
These operation instructions are part of the product.
●
Retain operation instructions during product life.
●
Pass on instructions to any subsequent user or owner of the product.
Purpose of the document:
This document contains information for installation, commissioning, operation and maintenance staff. It is intended
to support device installation and commissioning.
Reference documents:
●
Manual (Operation and setting ) of actuator controls ACV 01.2 Modbus
●
Manual (Fieldbus device integration) of actuator controls ACV 01.2 Modbus
Reference documents can be downloaded from the Internet (www.auma.com) or ordered directly from AUMA
(refer to <Addresses>).
Table of contents Page
51. Safety instructions.................................................................................................................
51.1. Basic information on safety
51.2. Range of application
61.3. Applications in Ex zone 22 (option)
71.4. Warnings and notes
71.5. References and symbols
92. Identification...........................................................................................................................
92.1. Name plate
112.2. Short description
133. Transport, storage and packaging........................................................................................
133.1. Transport
143.2. Storage
153.3. Packaging
164. Assembly................................................................................................................................
164.1. Mounting position
164.2. Handwheel fitting
164.3. Multi-turn actuator: mount to valve/gearbox
164.3.1. Output drive type A
174.3.1.1. Stem nut: finish machining
184.3.1.2. Multi-turn actuator (with output drive type A): mount to valve
194.3.2. Output drive types B
204.3.2.1. Multi-turn actuator with output drive types B: mount to valve/gearbox
214.4. Accessories for assembly
214.4.1. Stem protection tube for rising valve stem
224.5. Mounting positions of local controls
224.5.1. Mounting positions: modify
235. Electrical connection.............................................................................................................
235.1. Basic information
265.2. SD electrical connection (AUMA plug/socket connector)
275.2.1. Terminal compartment (for mains connection): open
2
SAV 07.2 – SAV 16.2 / SARV 07.2 – SARV 16.2 Control unit: electronic (MWG)
Table of contents ACV 01.2 Modbus RTU
