Safety standards
Safety measures and safety equipment must comply with the respectively valid
national on site specifications. All externally connected devices shall comply with
the relevant safety standards for the place of installation.
Connecting cables
●
We recommend using connecting cables and connecting terminals according
to rated current (I
N
) (refer to motor name plate or electrical data sheet).
●
For device insulation, appropriate (voltage-proof) cables must be used. Specify
cables for the highest occurring rated voltage.
●
Use connecting cable with appropriate minimum rated temperature.
●
For connecting cables exposed to UV radiation (outdoor installation), use UV
resistant cables.
●
For the connection of position transmitters, screened cables must be used.
Cable installation in ac-
cordance with EMC
Network cables are sensitive to interference. Motor cables are interference sources.
This product potentially causes high frequency interference!
→
The measures eliminating interference described hereafter must be observed
for cable installation in accordance with EMC.
●
Use shielded power cable and earth shield at both ends.
●
Lay cables being susceptible to interference or sources of interference at the
highest possible distance from each other.
●
The interference immunity of network cables increases if the cables are laid
close to the earth potential.
●
If possible, avoid laying long cables and make sure that they are installed in
areas being subject to low interference.
●
Avoid parallel paths with little cable distance of cables being either susceptible
to interference or interference sources.
●
In a residential environment, this product may cause radio interference, in which
case supplementary mitigation measures might be required.
Network cables
This device is equipped with a network port.
Table 11:
Cable recommendation
Only network cables suitable for Industrial Ethernet are to be used.
Cat.5e for fixed installation, 2x2xAWG22 structureMinimum requirement
Cat.6e for fixed installation, 2x2xAWG22 structureCable recommendation
Prior to installation, please note:
●
Install network cables at a distance of minimum 20 cm to other cables.
●
If possible, network cables should be laid in a separate, conductive, and earthed
cable tray.
●
Ensure absence of equipotential earth bonding differences between the indi-
vidual devices within the network (perform an equipotential earth bonding).
●
Do not use network hubs.
Table 12:Transmission rate/cable length for star topology or point-to-point wiring
Maximum cable length: between two network participants for copper cablesBaud rate (kbit/s)
100 m10/100 Mbits/s
26
SAV 07.2 – SAV 16.2 / SARV 07.2 – SARV 16.2 Control unit: electronic (MWG)
Electrical connection ACV 01.2 Modbus TCP/IP
