AUMA SAVEx Series - Page 101

Please state device type and our order number (see name plate) when ordering spare parts. Only original AUMA spare parts should be used.
Failure to use original spare parts voids the warranty and exempts AUMA from any liability. Representation of spare parts may slightly vary
from actual delivery.
TypeDesignationRef. no.
Sub-assemblyLocal controls002.0
Sub-assemblyLocal controls board002.3
Face plate for display002.4
I/O board008.1
Sub-assemblyFieldbus board008.1
Sub-assemblyLogic board009.0
Sub-assemblyRelay board011.1
Power supply unit/DC link013.0
Sub-assemblyMotor controller/switchgear014.0
Pin carrier without pins502.0
Pin for controls505.0
Sub-assemblyPin for motor506.0
Padlock509.1
Sub-assemblyFuse kit510.0
Sub-assemblyTerminal frame (without terminals)528.0
End clamp529.0
Sub-assemblyCable conduit (actuator connection)532.0
Terminals for motor/controls533.0
Retaining ring535.1
Sub-assemblyEx plug/socket connector with terminal blocks (KES)573.0
Cover607.0
Sub-assemblySwitchgear housing633.0
SetSeal kitS
101
SAVEx 07.2 – SAVEx 16.2 / SARVEx 07.2 – SARVEx 16.2 Control unit: electronic (MWG)
ACVExC 01.2 Non-Intrusive Modbus RTU Spare parts
