13.2. Technical data Actuator controls
Features and functions
Refer to name plateExplosion protection
Certificates are attached to the device. All standards applied and their respective issues are indicated
on these certificates.
Certificates and standards
The particular conditions of use are listed on the certificates supplied.Particular conditions of use
Standard voltages AC:
1-phase AC
Voltages/frequencies
3-phase AC
Voltages/frequencies
220 – 240110 – 120Volt380 – 480220 – 240Volt
60506050Hz60506050Hz
Permissible variation of mains voltage: ± 10 %
Permissible variation of mains frequency: ± 5 %
Power supply
24 V DC: +20 % / –15 %
Current consumption: Basic version approx. 250 mA, with options up to 500 mA
External power supply must have reinforced insulation against mains voltage in accordance with
IEC 61010-1 and may only be supplied by a circuit limited to 150 VA in accordance with IEC 61010-1.
External supply of the electronics
(option)
The controls are designed for the rated motor power, refer to motor name plateRated power
Via Modbus RTU interfaceControl and feedback signals
●
2 free analogue inputs (0/4 – 20 mA), 4 free digital inputs
-
Signal transmission is made via fieldbus interface
●
Inputs OPEN, STOP, CLOSE, EMERGENCY, I/O interface, MODE (via opto-isolator thereof OPEN,
STOP, CLOSE, MODE with one common and EMERGENCY, I/O interface respectively without
common)
-
Control inputs: OPEN, STOP, CLOSE, EMERGENCY
-
I/O interface: Selection of control type (fieldbus or additional input signals)
-
MODE: Selection between open-close duty (OPEN, STOP, CLOSE) or modulating duty (0/4 –
20 mA position setpoint)
-
Additionally 1 analogue input (0/4 – 20 mA) for position setpoint
●
Inputs OPEN, STOP, CLOSE, EMERGENCY, I/O interface, MODE (via opto-isolator thereof OPEN,
STOP, CLOSE, MODE with one common and EMERGENCY, I/O interface respectively without
common)
-
Control inputs: OPEN, STOP, CLOSE, EMERGENCY
-
I/O interface: Selection of control type (fieldbus or additional binary OPEN, STOP, CLOSE input
signals)
-
MODE: Selection between OPEN - CLOSE control and setpoint control (0/4 – 20 mA)
-
Additionally 1 analogue input (0/4 – 20 mA) for setpoint position and 1 analogue input (0/4 – 20
mA) for actual process value
Fieldbus interface
with additional input signals (option)
24 V DC, current consumption: approx. 10 mA per inputStandardControl voltage/current consumption
for control inputs
48 V DC, current consumption: approx. 7 mA per input
60 V DC, current consumption: approx. 9 mA per input
115 V DC, current consumption: approx. 15 mA per input
100 – 120 V AC, current consumption : approx. 15 mA per input
Options:
All input signals must be supplied with the same potential.
Via Modbus RTU interfaceStatus signals
90
SAVEx 07.2 – SAVEx 16.2 / SARVEx 07.2 – SARVEx 16.2 Control unit: electronic (MWG)
Technical data ACVExC 01.2 Non-Intrusive Modbus RTU
