AUMA SQ 05.2 Operation Instructions

Control
Table 3:
Control examples (indications on actuator controls name plate)
DescriptionInput signal
Control voltage 24 V DC for OPEN-CLOSE control via digital inputs (OPEN,
STOP, CLOSE)
24 V DC
Control voltage 48 V DC OPEN-CLOSE control via digital inputs (OPEN,
STOP, CLOSE)
48 V DC
Control voltage 60 V DC OPEN-CLOSE control via digital inputs (OPEN,
STOP, CLOSE)
60 V DC
Control voltage 115 V AC for OPEN-CLOSE control via digital inputs (OPEN,
STOP, CLOSE)
115 V AC
Input current for setpoint control via analogue input0/4 – 20 mA
Data Matrix code
When registered as authorised user, you may use our AUMA Assistant App to scan
the Data Matrix code and directly access the order-related product documents without
having to enter order number or serial number.
Figure 7: Link to AUMA Assistant App:
For further Service & Support, software/apps/... refer to www.auma.com.
2.2. Short description
Part-turn actuator
Definition in compliance with EN 15714-2/EN ISO 5211:
A part-turn actuator is an actuator which transmits a torque to the valve for less than
one full revolution. It need not be capable of withstanding thrust.
AUMA part-turn actuators SQEx 05.2 – SQEx 14.2/SQREx 05.2 – SQREx 14.2 are
driven by an electric motor. For manual operation, a handwheel is provided. Switching
off in end positions may be either by limit or torque seating. Actuator controls are
required to operate or process the actuator signals.
Actuator controls
ACExC 01.2 actuator controls are used to operate AUMA actuators and are supplied
ready for use.The actuator controls may be mounted directly to the actuator or
separately on a wall bracket.
The functions of ACExC 01.2 actuator controls include standard valve control in
OPEN-CLOSE duty, positioning, process control, logging of operating data right
through to diagnostic functions.
Local controls/
AUMA software
Operation, setting, and display can be performed directly at actuator controls or
alternatively from Remote via binary input signals.
The following options are available at the actuator controls in local operation:
●
The actuator can be operated via the push buttons of the local controls or set-
tings can be made in the actuator controls menu.The display shows information
on the actuator as well as menu settings (contents of these instructions).
●
Using the AUMA CDT software for Windows-based notebooks or the AUMA
Assistant App for Android-based devices, data can be uploaded and read
whereas settings can be modified and stored.The connection between computer
and actuator controls is wireless via Bluetooth interface (not included in these
instructions). AUMA CDT software can be downloaded free of charge from our
website www.auma.com.
Intrusive - Non-Intrusive
●
Intrusive version (control unit: electromechanical):
Limit and torque setting is performed via switches in the actuator.
12
SQEx 05.2 – SQEx 14.2 / SQREx 05.2 – SQREx 14.2 Control unit - electromechanical
Identification ACExC 01.2 Intrusive
