AUMA SQ 05.2 Operation Instructions

Required user level: Specialist (4) or higher.
Diagnostic M0022
TMS proof test M1950
Test procedure:
1. Set selector switch to position 0 (OFF).
2.
Return to the main menu and select the simulation value: Thermal test in
parameterTMS proof test M1950.
3.
Activate motor protection simulation: Press Ok push button.
The safety function is correct if no fault signal is displayed.
4.
Reset simulation: Press Ok push button or exit the simulation menu and reset
the selector switch to its initial position.
78
SQEx 05.2 – SQEx 14.2 / SQREx 05.2 – SQREx 14.2 Control unit - electromechanical
Corrective action ACExC 01.2 Intrusive
