Service conditions
IP68
Terminal compartment additionally sealed against interior of actuator (double sealed)
For special motors differing enclosure protection: refer to name plate.
Enclosure protection according to
EN 60529
According to AUMA definition, enclosure protection IP68 meets the following requirements:
●
Depth of water: maximum 8 m head of water
●
Duration of continuous immersion in water: Max. 96 hours
●
Up to 10 operations during continuous immersion
●
Modulating duty is not possible during continuous immersion.
For exact version, refer to actuator controls name plate.
Pollution degree 4 (when closed), pollution degree 2 (internal)Pollution degree according to
IEC 60664-1
2 g, 10 to 200 Hz (AUMA NORM), 1g, 10 to 200 Hz (for actuators with AMExC or ACExC integral actu-
ator controls)
Resistant to vibration during start-up or for failures of the plant. However, a fatigue strength may not be
derived from this.Valid for part-turn actuators in version AUMA NORM and in version with integral actu-
ator controls, each with AUMA plug/socket connector. Not valid in combination with gearboxes.
Vibration resistance according to
IEC 60068-2-6
KS: Suitable for use in areas with high salinity, almost permanent condensation, and high
pollution.
Standard:Corrosion protection
KX: Suitable for use in areas with extremely high salinity, permanent condensation, and
high pollution.
Option:
KX-G: Same as KX, however aluminium-free version (outer parts)
Double layer powder coating
Two-component iron-mica combination
Coating
AUMA silver-grey (similar to RAL 7037)Standard:Colour
Available colours on request.Option:
AUMA part-turn actuators meet or even exceed the lifetime requirements of EN 15714-2. Detailed in-
formation can be provided on request.
Lifetime
Further information
ATEX Directive: (2014/34/EU)
Electromagnetic Compatibility (EMC): (2014/30/EU)
Low Voltage Directive: (2014/35/EU)
Machinery Directive: (2006/42/EC)
EU Directives
Technical data for limit and torque switches
2 x 10
6
startsMechanical lifetime
Silver plated contacts:
24 V AC/DCU min.
250 V AC/DCU max.
20 mAI min.
5 A at 250 V (resistive load)
3 A at 250 V (inductive load, cos phi = 0.6)
I max. AC current
0.4 A at 250 V (resistive load)
0.03 A at 250 V (inductive load, L/R = 3 µs)
5 A at 30 V (resistive load)
5 A at 30 V (inductive load, L/R = 3 µs)
I max. DC current
Gold plated contacts
5 VU min.
50 VU max.
4 mAI min.
400 mAI max.
86
SQEx 05.2 – SQEx 14.2 / SQREx 05.2 – SQREx 14.2 Control unit - electromechanical
Technical data ACExC 01.2 Intrusive
