Valve damage due to excessive torque!
→
Only apply torque by-pass with the consent of the valve manufacturer.
Torque by-pass: activate
Customer settings M0041
Torque switching M0013
Torque by-pass M0092
Default value:Function not active
Setting values:
Function active
The torque by-pass is activated.
Function not active
The torque by-pass is deactivated.
Time interval for torque by-pass
During the time interval set here, the torque monitoring is deactivated.
Customer settings M0041
Torque switching M0013
Torque by-pass [s] M0205
Default value: 0.0 s
Setting range: 0.0 ... 10.0 s seconds
Information
If torque by-pass is activated, the interval should be longer than the set time period
for reversing prevention time to ensure torque by-pass will also be effective in the
event of reversal of operation.
10.1.2. Torque limitation of torque by-pass
For activated torque by-pass, the torque monitoring (parameter Torque by-pass
M0092) is deactivated for a defined (short) time. By activating the torque limitation,
torque monitoring will be activated again, but not in relation to the set tripping torque
but in relation to a torque peak which can be set separately via this function.
Condition
Electronic control unit with MWG in the actuator (non-intrusive version).
Activate torque limitation
Customer settings M0041
Torque switching M0013
Torque limitation M1805
Default value:Function not active
Setting values:
Function active
The torque limitation of the torque by-pass is activated.
The actuator will be stopped during the by-pass interval and a torque fault will be
generated once the permitted torque peak has been exceeded.
Function not active
The torque limitation of the torque by-pass is deactivated.
There is no torque monitoring. During the by-pass interval, no torque fault will be
generated.
Set torque peak
Customer settings M0041
Torque switching M0013
Torque peak [%] M1806
Default value: 120 %
Setting range: 100 ... 150 % (in relation to the set tripping torque)
106
Actuator controls
Monitoring functions ACV 01.2/ACVExC 01.2 Profibus DP
