AUMA SQV 05.2 User Manual

Individual indications
RemedyIndication on display
Check actuator.
IE position transmitter
Check logic.
IE logic
Check fieldbus interface.
IE fieldbus
Check MWG.
IE MWG
Check local controls.
IE LC
Internal error: Calibration of Hall sensor 1 – 5 of the MWG is incorrect.
Check MWG.
IE Hall 1 calibration –
IE Hall 5 calibration
Check MWG.
IE MWG calibration
Check device configuration.
IE version
Check device configuration.
IE EEPROM
Check device configuration.
IE parameter
Check device configuration.
IE file access
Check device configuration.
IE reserve backup
Check device configuration.
IE registration
Check device configuration.
IE startup FB
Check device configuration.
IE startup sub-assy
Check device configuration.
IE LC exception
Check device configuration.
IE logic exception
Check device configuration.
IE MWG exception
Check device configuration.
IE bus exception
Check device configuration.
IE MWG end positions
Internal warning (Collective signal 15)
Check heater.
Wrn heater
The 24 V DC customer auxiliary supply to control the digital inputs has failed.
Check 24 V DC inputs (DIN).
24 V DC customer
The internal 24 V DC power supply of the controls used to provide the electronics components (sub-
assemblies within the AC 01.2 controls and in the actuator) has exceeded the power supply limits .
Check internal 24 V DC voltage supply.
24 V DC internal
Reboot AUMATIC.
Wrn res. data in use
Operate actuator fully in end positions OPEN and CLOSED.
Wrn ref.actual position
Verify primary reduction gearing settings within the actuator.
Wrn range act.pos.
Check position feedback.
Wrn sign.loss act.pos.
Check system configuration.
Wrn event mark
Check system configuration.
Wrn Tm mark
Config. error REMOTE (Collective signal 22)
●
Check I/O interface M0139 parameter.The setting must correspond to the wiring diagram.
●
Check wiring.
●
Check I/O interface.
IE I/O interface
Check configuration.
IE remote interface
Check configuration.
IE remote Prm Config
149
Actuator controls
ACV 01.2/ACVExC 01.2 Profibus DP Corrective action
