Austroflamm Clou Pellet - Technical Data; Clou Pellet 8 kW; 10 kW

Clou Pellet / Clou Compact Pellet User instruction 30 English
10 Technical data
Clou Pellet 8 kW / 10 kW
Distance to combustible parts
Nominal heat efficiency (NHE)
8 / 10 kW
Heat output at partial load (PL)
2,4 / 2,4 kW
Room-heating capacity
98 - 255 / 128 – 350 m³
Efficiency
≥90 %
CO content at NHE
<250 mg/Nm³
Flue gas temperature at NHE
200 / 229 °C
Flue gas temperature at PL
106 / 106 °C
Exhaust gas mass flow at nominal heat efficiency
5,51 / 6,18 g/s
Chimney draught
3-12 Pa
Filling tank capacity
36 kg / 56 l
Pellet consumption min./max.
0,6 – 1,87 / 0,71 – 2,36 kg/h
Burning time min./max.
≈19 – 60 / ≈15-50 h
Air inlet nozzle Ø
80 mm
Flue gas outlet Ø
80 mm
Electrical power consumption when switching on
300 W
Electrical power consumption during operation
<20 W
Voltage / current frequency
230 V / 50 Hz
Dimensions
H x W x D
1100 x 630 x 510 mm
Weight
173 kg
Minimum clearance
at the side
(wall)
100 / 150 mm
rear
100 / 100 mm
front
800 / 1000 mm
Temperature limits
5 – 40 °C
Relative humidity
non-condensing
