Austroflamm Clou Pellet - Clou Compact Pellet 6 kW

Clou Pellet / Clou Compact Pellet User instruction 37 English
Clou Compact Pellet 6 kW
Distance to combustible parts
Nominal heat efficiency (NHE)
6 kW
Heat output at partial load (PL)
1,5 kW
Room-heating capacity
65 – 165 m³
Efficiency
≥90 %
CO content at NHE
<250 mg/Nm³
Flue gas temperature at NHE
170 °C
Flue gas temperature at PL
85 / 85 °C
Exhaust gas mass flow at nominal heat efficiency
4,78 g/s
Chimney draught
3-12 Pa
Filling tank capacity
26 kg / 40 l
Pellet consumption min./max.
0,5 - 1,55 kg/h
Burning time min./max.
≈16 - 52 h
Air inlet nozzle Ø
80 mm
Flue gas outlet Ø
80 mm
Electrical power consumption when switching on
300 W
Electrical power consumption during operation
<20 W
Voltage / current frequency
230 V / 50 Hz
Dimensions
H x W x D
1033 x 520 x 499 mm
Weight
150 kg
Minimum clearance
at the side
(wall)
100 mm
rear
100 mm
front
800 mm
Temperature limits
6 kW
Relative humidity
non-condensing
