4 Product overview
4.1 Intended use
The Austroflamm pellet stove described in this manual is manufactured and tested as a type A1 self-
closing appliance.
NOTICE
Operation is only permitted with the door shut, ash pan locked and hopper lid closed.
4.2 Identification of the product
In the following illustrations we will inform you of dimensions and the nameplate positioning.
4.2.1 Dimensions
00
00
00
00
453
45
440
475 495
1120
1145
80
120
120
690
60
80
80
132
547
252
140238
417
Fig.2: Ruby dimensions
