Appendix
Fault Code List
The table below contains the fault codes on the Autel Charge Cloud and their descriptions on the Autel
Charge app.
Fault Codes Descriptions
01 Mains overvoltage
02 Mains undervoltage
04 Mains over-frequency
08 Mains under-frequency
10 Phase loss
20 Line/Neutral reverse connection
40 Ground fault
80 Abnormal shutdown
100 Over-temperature
200 Leakage current
400 CP voltage abnormal/grounded
800 Contactor abnormal
1000 Output overcurrent
2000 Vehicle S2 failure
4000 Vehicle CP negative failure
8000 PP signal disconnected
10000 PP signal abnormal
20000 Electronic lock fault
40000 PME fault
80000 PME failed to disconnect relay
100000 COMM error with control board
200000 Electric meter abnormal
400000 Data error
800000 Leakage current (AC)
1000000 Trip fault
2000000 Sensor self-test fault
