7.2 USE IN EMERGENCY CONDITIONS
7.2.1 UP - CLOSING
The back up manual pump is used to drive the hydraulic lift if there is no electric current.
The pump controls consist of the extension of the hydraulic lift platform lifting pump arm and the metal
slide protruding from the hydraulic power unit casing.
To lift the platform, insert the pump arm extension (1) in the metal cylinder protruding from the hydraulic
power unit (2).
Move the arm alternately up and down (3) to raise the platform to the point of full closure.
After the operation, replace the extension (1) in the housing and contact your Autolift agent or authorised
installer.
