door – outside front
Item
No. Part No. Description
1 340044-9 Top Trim Vantage.
2 201690-2 Top Trim Insert. True Grit Black.
201690-15 Top Trim Insert. Dark Gray
3 340057-2 Trim Outside Vertical.Black. Right & Left Side.
4 202059-52 Panel, Left Side Vertical.Sterling Royce.
202059-48 Panel, Left Side Vertical.White.
202059-50 Panel, Left Side Vertical.Dove Gray.
202059-8 Panel, Left Side Vertical. Painted.
5 340058-46 Trim Vertical.Window. Black, Right & Left Side.
6 750141 Front Window. (44 5/8 x 26 7/8 x 1/8).
NOTE Replacement Glass Must Be
Hard Tempered or Lexan Only.
7 340058-5 Trim Horizontal.Window. Black.
8 201356-1 Delivery Tray Panel. True Grit Black.
9 640154
Assembly, Lower Door Hinge Plate. Specify Color.
10 201678 Bottom Door Edging.
11 420186 Screw Pan Hd.#2 Drill Pt 6-20.
12 201692-1 Lower Horizontal Panel. Black.
201692-56 Lower Horizontal Panel. Dark Gray.
201356-43 Delivery Tray Panel. Dark Gray.
13 440296 Coin Cup Trim. Black.
440296-1 Coin Cup Trim. Dark Brown.
440296-2 Coin Cup Trim.Medium Gray.
201156 Coin Cup Door.
Item
No. Part No. Description
14 202061-42
Panel, Right Side Vertical.Lower. Sterling Royce
202061-38 Panel, Right Side Vertical. Lower. White.
202061-40 Panel, Right Side Vertical. Lower. Dove Gray.
202061-7 Panel, Right Side Vertical. Lower. Painted.
15 420071 Ace Lock W/2 Keys.
420071-1 Ace Lock W/1 Key.
420071-2 Ace Lock W/O Key.
16 660319 Assembly Lock Handle W/Lock Arm & Nut.
420146 Lock Handle Only.
17 660368 Assembly Complete. Selection Panel.
See Page #21 for Itemized Parts.
18 600600 Door Only. Specify Color.
600600-1 Door Only. European Style. Specify Color.
600600-2 Door Only. With Validator Hole And Debit Card
Use. Specify Color.
19 201678-6 Top Lock Door Edging.
20 202060-50 Panel, Right Side Vertical. Upper. White.
202060-52 Panel, Right Side Vertical. Upper. Dove Gray.
202060-8 Panel, Right Side Vertical. Upper. Painted.
202060-54 P
anel, Right Side Vertical.Upper. Sterling Royce.
14
