Automatic Products SNACKSHOP 113 - Delivery bin

swing out – panel assembly
Item
No. Part No. Description
Item
No. Part No. Description
delivery bin
1 660558 Delivery Bin Assembly. Complete. Black.
660558-2 Delivery Bin Assembly. Complete. Gray.
600704 Delivery Bin.
2 640187-1 Arm Mounting Bracket.
3 438-8 Nut, Keps. No. 8-32.
4 640098 Inner Door Bin Arm.
5 640100-1 Bin Door Drive Assembly.
6 751-37 Retaining Ring No. 37.
7 750183 Kit, Lower Bracket Repair.
8 640097 Door Drive Arm.
9 440129 Door Bearing.
420282 Bin Door Washer (Not Shown).
10 200763 Inner Door.
200763-5 Inner Door Steel
11 276-846 Screw, Pan Hd., Self Tap. (8-32 x 3/8)
12 440373 Door, Delivery Bin.Black.
440373-2 Door, Delivery Bin.Gray.
15 202285 Arm Mounting Bracket (Lock Side).
16 200902 Baffle, Rear Delivery Bin.
17 200906 Delivery Bin Anchor Strap.
18 420315 Delivery Bin Pad Assembly for Can
Dispenser.
32
