Automatic Products SNACKSHOP 113 - Connector Pinouts

P1 POWER IN
1 24 VAC HOT
2 KEY
3 24 VAC NEUTRAL
4 7.0 VAC HOT
5 7.0 VAC NEUTRAL
6 4.7 VAC HOT
7 4.7 VAC NEUTRAL
8 4.7 VAC CENTER TAP
9 24 VAC 50 Ma
10 24 VAC 50 Ma
P2 MOTOR DRIVE
1 ROW A
2 ROW B
3 ROW C
4 ROW D
5 ROW E
6 ROW F
7 ROW G
8 ROW H
9 COL 1
10 COL 2
11 COL 3
12 KEY
13 COL 4
14 COL 5
15 COL 6
18 COL 7
17 COL 8
18 COL 9
19 COL 10
P3 DISPLAY
1 FIL
2 FIL
3 5VDC
4 DOR
5 CT
6 -27VDC
7 DATA
8 CLOCK
9 DOR
10 SERIAL RES. 5VDC
11 SERIAL RES. SIGNAL
12 OPTICS GND
13 OPTICS RECEIVE
14 OPTICS TRANSMIT
15 OPTICS 5 VOLTS
P4 MODE KEY SWITCH
1 KEY SWITCH CONTROL
2 KEY SWITCH M/O
P5 - DOOR SWITCH
1 SIGNAL
2 GND
P6 - BILL VALIDATOR
1 ESCRCW HIGH
2 $1 HIGH
3 $2 HIGH
4 $5 HIGH
5 ESCROW ENABLE (LOW)
6 $ ENABLE
7 $ ENABLE
8 $ ENABLE
9 CREDIT
10 (KEY)
11 GND
12 24VAC HOT
13 24VAC NEUTRAL
14 +15 VDC
15 +9.75 VDC
P7 TRC-6000/6010 Series Mech
1 24 VDC RET NF
2 KEY
3 24 VDC HOT NF
4 KEY
5 DATA
6 INT
7 AE
8 MECH RESET
9 SEND
10 +5VDC
11 GND
12 .05¢ DISPENSE
13 .10¢ DISPENSE
14 .25¢ DISPENSE
15 $1.00 DISPENSE
P9 - MS 1600/EUROPEAN CARD READER
1 REC +
2 REC
3 XMIT
4 GND
5 XMIT +
6 24VAC HOT
7 KEY
8 24 VAC NEUTRAL
9 EXACT CHANGE
P10 - RS232 SERIAL INTERFACE
1 RECEIVE DATA
2 GND
3 TRANSMIT DATA
4 KEY
5 GND
49
connector pinouts
