Automatic Products SNACKSHOP 113 - Swing-Out Panel Assembly

swing out – panel assembly
Item
No. Part No. Description
Item
No. Part No. Description
22
1 660446 Assembly Complete, Swing Out Panel.
600614 Panel Only.
2 680310 Door Operate Switch Harness.
3 380258 Door Operate Switch.
4 420095 P.C. Board Stand Off.
5 360165 Control Board.
380308 Battery (Not Shown)
6 660368 Front Bezel, Assembly Complete. Black.
660368-1 Front Bezel, Assembly Complete. Brown.
660368-2 Front Bezel, Assembly Complete. Gray.
320057-1 Front Bezel Only.
7 440310 Display Lens.
8 440304 Selector Button. Quantity 20.
460415 Decal, Selector Button Background, Black.
460415-1 Decal, Selector Button Background,
Dark Brown.
460415-2 Decal, Selector Button Background,
Medium Gray.
9 660366 Selector Switch & Plate Assembly.
10 460414 Bezel Background. Black.
460414-1 Bezel Background. Multicard.
460414-2 Bezel Background. Dark Brown.
460414-3 Bezel Background.Medium Gray.
11 440309 Coin Entrance.
440309-1 Coin Entrance (Use W/Debitek Only).
11A 460416 Decal, Coin Return Button. Black.
460416-1 Decal, Coin Return.Dark Brown.
460416-2 Decal, Coin Return. Medium Gray.
11B 460417 Decal, Right Side Insert Filler. Black.
460417-1 Decal, Right Side Insert Filler. Dark Brown.
460417-2 Decal, Right Side Insert Filler. Medium Gray.
12 660370 Assembly, Validator Filler. Black.
460424 Validator Decal Only. Black.
660370-1 Assembly, Validator Filler. Dark Brown.
460424-1 Validator Decal Only. Dark Brown.
660370-2 Assembly, Validator Filler. Medium Gray.
460424-2 Validator Decal Only. Medium Gray.
460424-4 Validator Decal. Dark Gray.
460636 Validator Decal French
202708 Adaptor Bracket CBV (Not Shown).
13 660371 Debit Card Filler Assembly. Black.
460425 Debit Card Decal Only. Black.
660371-1 Debit Card Filler Assembly. Dark Brown.
460425-1 Debit Card Decal (Use w/Debitek Only).
460425-2 Debit Card Decal Only. Dark Brown.
660371-2 Debit Card Filler Assembly. Medium Gray.
460425-3 Debit Card Decal Only. Medium Gray.
460637 Debit Card Decal Only French
15 18443 Hex Nut 1/4 Self Threading.
16 680457 Connector Ribbon - Control Board.
17 360166 Display Board W/O Optics.
360166-1 Display Board W/Optics.
460533 Display Board Pad.
18 200-6R6 Screw, Rd. Hd. Type AB #6.
19 276-8R6 Screw, Pan.Had. Phil. Type 23 #8-32 x 3/8.
20 440289 Coin Return Button.Gray.
440289-2 Coin Return Button (Use w/Debitek Only).
440289-3 Coin Return Button.Black.
21 201660 Coin Return Support Bracket.
22 660488 Coin Chute Assembly. Plastic.
23 660367 Coin Return, Assembly Complete.
640152 Coin Return Bracket Only.
751-25 Retaining Ring (1/4).
400034 Spring, Indexing Lever.
24 201703 Coin Return Link.
25 440311 Coin Chute.
26 201712 Coin Chute Support Bracket.
27 660445 Panel Latch, Assembly Complete.
202121 Latch, Bracket Only.
28 437-41 Nut 1/4-28 Keps.
29 440362 Shelf Roller.
30 300203 Shelf Roller Screw.
31 660448 Control Board Cover Assembly.
660448-3 Control Board Cover Assembly England
660448-2 Control Board Cover Assembly French
202175 Cover Only.
32 420040-3 Hole Snap Bushing.
33 460514 Instructions, Control Board.
460539 Instructions, Control Board. French.
460657 Instructions, Control Board England
460575 Instructions, Control Board Export
34 202136 Panel Stop. (111,112 Only).
35 750182 Assembly Complete. Coin Chute.
(2 pcs.)
