cabinet
Item
No. Part No. Description
1 750100-4 Cabinet Assembly Complete. With Legs.
Specify Color. (113)
750100-5 Cabinet Assembly Complete With Legs
Specify Color. (114)
2 202119 Filler Plate. Left Front.
3 600310 Assembly, Cabinet to Door Filler.
Specify Color.
4 276-8R6 Screw, Pan Hd.Self Tap. (8-32 x 3/8)
5 202120 Shelf Support. Left Front.
6 640177 Assembly, Cabinet Shelf Track. Left.
7 201386 Gum & Mint Filler Panel. (Use w/o G/M Shelf).
8 See Page #21 For Itemized Parts.
9 See Page #33 For Itemized Parts.
10 640177-1 Assembly, Cabinet Shelf Track. Right.
11 202177 Cabinet Receptacle Mounting Bracket Only.
12 420142-2 Drive Pin.
13 660442
Assembly Comp. Cabinet Back Harn.5 Shelves
.
660442-1 Assembly Comp. Cabinet Back Harn.
6 Shelves.
660442-4 Harness Cabinet Back.
6 Shelves 114 only.
Item
No. Part No. Description
14 404-6 Nut, Hex Hd. (6-32)
15 380303 Assembly, Line Filter.
16 660492 Assembly Complete. Light Ballast & Filter.
115 Volt
660492-1 Assembly Complete. Light Ballast
Filter. 220 Volt.
660492-2 Assembly Complete. Light Ballast
Filter. 240 Volt.
202251 Cover Mounting Plate Only.
17 276-6R6 Screw, Pan Hd.(6-32 x 3/8).
18 680514 Ballast Only. 115 Volt.
680513-1 Ballast Only. 220 Volt.
680513 Ballast Only. 240 Volt.
19 360163 Power Inlet Cord Only.
660506 Assy. Complete Power Cord w/plate.
660505-1 Assy. Complete Power Cord w/plate.
20 380052-3 Strain Relief Bushing w/screw.
21 420078-1 Pop Rivet.
22 202270 Power Inlet Cord Plate.
23 202238 Validator Guard.
680455-4 Ground Wire
18
