trouble shooting chart
Problem Cause Remedy
Says make another selection Motor
1
⁄2 cycled Home motor and retry /LCM do
mode 5 test vend
Selection lost its price Reset prices
Motor won't turn Swap shelves with another shelf
and retry
Check shelf harness connection
to board
Check 24VAC to logic board
(blue wires 110) /white wires
LCM
Display messages "Machine use not allowed" Machine set in shutdown mode
see mode 800 in manual
"Buy now & save X%" Machine set in discount mode
see mode 900 in manual
"Free" Winner vend set to 01
Discount set on
Selection priced at 00.00
Free vend on
Use correct change Coin tubes empty Re-fill coin tubes
Says use correct change Replace coin mechanism
with coin tubes full
Spirals turn more than one turn Capacitor discharging current Re-solder capacitor or replace
motor
Loose wire on motor Repair wire
Defective motor switch Replace switch
Defective control board Replace control board
More than one motor turns One of the motor wires is Check each individual motor
together shorting out for loose or pinched wire
Defective control board Replace control board
Incorrect vend motors Black bodied motors for LCM
installed
Ivory bodied motors for 110
series
47
