ATS Series Instruction Manual8
10. Optional Safety Beam Kit
Safety Beams
The Safety Beam Kit provides additional safety by preventing the door closing when
the beam is blocked by a car, child etc. When the Safety Beam Kit is installed the
Auto-close feature can be enabled if required.
a. To install the Safety Beam Kit, refer to the Safety Beam instruction supplied with
the kit.
b. After the beams are installed the beam alignment feature of the opener can be
used.
c. Turn power on to the opener.
d. Align the safety beams using the main light as a guide:
i. bright = aligned
ii. dull = not aligned or blocked
When the beam is aligned or if no beam is fitted, continue with Setting Limits.
