NeoSlider™ - Sliding Gate Opener NES-24V1 Owner Installation Instructions
24VDC output for powering accessories 3A(max)
Light relay driver
Lock relay driver
P.E input terminal
COM terminal for inputs terminals 6 - 11
OPN N/O input terminal
STP N/O input terminal
CLS N/O input terminal
OSC N/O input terminal
SWP N/O input terminal
PED N/O input terminal
Engage sensor microswith input
Console Previous button
Console Up/Open button
Console Next button
Console Exit button
Console Down/Close button
Console SET button
Antenna connector
Console display
PG3 programmer connector
Motor connector
24VAC input connector
10 AMP slow blow fuse
Standby battery charger/solar connector
02
01
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Control Board Layout
