NeoSlider™ - Sliding Gate Opener NES-24V1 Owner Installation Instructions
Parts List
When ordering spare parts please quote the order
code number to your installer/dealer.
Item/description order code
1. Base 62400
2. Mounting bracket ext 62502
3. Drive train ASSY V4 61882
4. Transformer TDB-150-08 kit 62025
5. EMC fi lter board EMC-3.02 61447
6. Timing platform CG8C 63229
7. Ext. spring 8.2 x 41 15681
8. Actuating Arm CG8C 15346
9. Chopper clip 64960
10. CAM limit ASSY 61702
11. Quad QMS-1.02 board 61673
12. E circlip D1500 0070 10815
13. Dust cover 63224
14. Worm 2315 64934
15. Sel-lock pin spring ACP M3 x 20 62576
16. DC motor 11_V4 ASSY 60383
17. PCB support 62430
18. Control board DCB02-2.00 60925
19. PCB cover ASSY ESV24/240 master 62490
20. Cover CG8C SP 62462
21. Top cover CG8C 62471
22. NeoSlider™ label 13578
23. Taptite screw ‘P’ M4 x 10 10570
24. Door 62420
25. Locks-key 64620
26. Top and bottom lock cap 15220
27. Microswitch ABS 111454 69261
28. M/SW harness ESV24/240 12240
29. Hinge pin 62560
30. Rod disengagement 62565
31. Antenna 433MHz L=1.95m coax cable 61972
32. Q-G 301 harness ASSY 61795
33. Gland MGB12-07B-ST-XA 65623
34. Plug - 8 x 32 11885
35. Button head screw ZnCROM M4 x 10 10027
36. Cap head screw M8 x 25 10070
37. Button head screw S.S M6 x 16 10023
38. Pan head screw ZnCROM M5 x 16 10474
39. Pan head screw w/washer M4 x 10 10340
40. Taptite screw ‘P’ M3 x 8 10560
41. Power cord 1.5m W2PIN + 1R 14150
42. Pan head screw M2.5 x 10 10375
43. Spring washer I.D 8 10950
44. Cable tie 4” GT-100M 14160
45. Spring washer I.D 5 10970
46. Plug - dia 21 hole 11881
47. Taptite screw ‘P’ M4 x 12 10569
48. Nylon gland M16-07B 65621
49. Earth terminal 65695
50. Int tooth lock washer I.D 4 11140
51. Hex nut M4 10890
52. Seration head screw M4 x 12 10380
53. Pan head screw w/washer M4 x 8 10320
54. Accessory actuator pack ESV 61463
55. Actuator block 15343
56. Actuator mounting block 15344
57. Taptite screw ‘P’ M4 x 30 10565
58. Wire earth ASSY 12150
