Owner Installation Instructions NeoSlider™ - Sliding Gate Opener NES-24V1 35
Specifi cations
Technical Specifi cations
Protection rating: IP33
Input voltage: 230V - 240V AC 50Hz
Transformer primary voltage: 230V/240VAC
Secondary voltage: 24V AC 150 VA
Controller voltage: 24V DC
Motor type: Permanent Magnet Direct Current
Motor voltage: 24V DC
Maximum pulling force: 200N
Maximum gate opening:
1,
Width:
Weight:
10m
250kg
Opener maximum
Opening/closing run time:
30 seconds
Receiver type: TrioCode™ OR Tri-Tran™
Receiver code storage capacity: 30 x 4 Button Transmitter Codes
Transmitter frequency: 433.47,433.92,434.37 MHz
Coding type: Hopping Code
No. of code combinations: Over 4.29 billion random codes
Code generation: Non-linear encryption algorithm
Transmitter battery: CR2032
NOTE:
1. The maximum gate size that the NeoSlider™ can be installed on is 10m wide and 250kg. The gate must be
well balanced. A person should be able to move the gate manually with very little effort (15kg force max.) in
case of an emergency.
2. The fi rst memory location sets the type of transmitters which can be stored into the receivers memory. It can
be either Automatic Technology TrioCode™ or B&D Tri-Tran™ transmit ters.
3. Intermittent operations may occur in areas which experience very strong wind gusts. A strong wind
puts extra pressure on the gate and tracks which may in turn trigger the safety obstruction detection
system intermittently.
NOTE: Specifi cations are subject to change without notice.
