20
NeoSlider™ - Sliding Gate Opener NES-24V1 Owner Installation Instructions
The opener’s standard operation can be altered by editing various parameters. This section describes
the parameters and the effect they have. Use the VIEWING AND EDITING PARAMETER PROCEDURE on
Page 23 to make changes.
Menu 2. Obstruction margins
The obstruction margins are used to alter the sensitivity of the allowable variation between the “normal” speed
profi le and the controller to obstructions. Increasing the value increases the actual running speed.
Control Board Adjustments
Parameter Min Max Default Step Unit Menu No.
M1 MARGIN Sets obstruction detection margin for M1 0.0 2.0 0.7 0.1 Amps 2
Standard Auto-Close
This mode is selected by entering a non-zero
time for the STD Auto-Close parameter. When
selected, the gate will auto-close after being fully
opened (except when the gate has reversed to
the open position after a motor obstruction or
overload). Countdown is suspended by: PE , OPN
or SWP input being active. The countdown is
aborted if the STP input is activated. If the gate
is already open and the OPN or the SWP input is
activated, then the countdown will start.
PE triggered Auto-Close
This mode is selected by entering a non-zero time
for the “PE Auto-Close” parameter. This mode is
used to auto-close the gate but only after a vehicle
have passed through the gateway and triggered
the PE input. The swipe input can be used to clear
the PE triggered status so that the PE input must
be activated again before the countdown will start.
As with the other PE modes the STP input will
abort countdown and the OPN and SWP inputs will
restart the countdown if the gate is OPEN.
Pedestrian access Auto-Close
This mode is selected by entering a non-zero time for
the “Ped’n A/C” parameter. When selected, the gate
will auto-close after being opened for pedestrian access
unless it was following a reverse from an obstruction.
PE triggered pedestrian Auto-Close
This mode is selected by entering a non-zero time
for the “PE Ped’n A/C” parameter. This mode is
the same as the PE triggered auto-close mode but it
only operates during pedestrian access. As the SWP
input is not available during pedestrian access, the
PED input can be confi gured to act in a SWP mode
by setting the “PED I/P = PED SWIPE MODE”
parameter to ON.
Auto-Close after obstruction
Two parameters are provided to enable the auto-close
feature to be activated after obstructions. Normally
the auto-close feature is not enabled after obstructions
for safety reasons. PE beams must be used for these
features to be activated.
Parameter Min Max Default Step Unit Menu No.
STD AUTOCLOSE TIME
Sets and enables the standard auto-close time
0.0 300.0 0.0 1.0 Sec 3
PE AUTOCLOSE TIME Sets and enables the PE
triggered auto-close time
0.0 60.0 0.0 1.0 Sec 3
PEDESTRIAN AUTOCLOSE TIME Sets and
enables the Pedestrian auto-close time
0.0 60.0 0.0 1.0 Sec 3
PE PEDESTRIAN AUTOCLOSE TIME Sets and
enables the PE Pedestrian auto-close time
0.0 60.0 0.0 1.0 Sec 3
AUTOCLOSE AFTER CLOSE OBSTRUCTION
Enables auto-close feature after close
obstructions
Off On Off 3
AUTOCLOSE AFTER OPEN OBSTRUCTION
Enables auto-close feature after open
obstructions
Off On Off 3
Menu 3. Auto-Close times
The Auto-Close modes automatically closes the gate after it has been operated. To implement this, the
controller starts a timer once the gate has reached its desired open position. The timer then counts down
and when it expires, the controller starts to close the gate. Details of the four Auto-Close modes are
outlined below. Automatic Technology strongly recommend using a PE Beam for added safety.
